| THE TECHNICAL PARAMETERS OF ZL18F CE CERTIFICATE MINI WHEEL LOADER | |||
| Item | Specifications | Item | Specifications |
| Rated loading weight | 1800kg | Overall dimensions(LxWxH) | 5300x1800x2750mm |
| Rated bucket capacity | 0.8m3 | Engine model | XINCHAI 498BT(EURO III) |
| Bucket width | 1750mm | Engine type | In-line arrangement, water cooled, four-cycle diesel engine |
| Track base | 1500mm | Engine starting mode | Electric |
| Wheel base | 2100mm | Rated power/Rated speed |
36.8KW/2500rpm |
| Min. turning radius(outside of rear wheels) | 4500mm | Brake mode | Four-wheel hydraulic spread -shoed brake |
| Min. Ground clearance | 260mm | Warranty | 12 months after received the goods |
| Dump height fully raised | 2700mm | Color | According to the requirements of customers |
| Max. Tilt angle | 300 | Tyre type | 20.5/70-16 |
| Max. Bucket breakout, lift cylinder |
36.8KN | Shipping port | Qingdao port, China |
| Maximum Speed | 21km/h | Packing details | Nude package, 1Unit/20’s GP with disassembled cabin, 3Units/40’s HQ |
| Driving mode | Four-wheel full hydraulic drive |
Delivery time | 15 days after confirm the order |
| Transmission gear box form | 2 gear hydraulic variable speed changes |
Supply ability | 100 units per month |
| Operating weight | 4150kg | ||
