THE TECHNICAL PARAMETERS OF ZL10FCE CERTIFICATE MINI WHEEL LOADER
|
|
Элемент
|
Specifications |
Элемент
|
Specifications
|
| Rated loading weight |
1000kg |
Эксплуатационная масса |
3300kg |
| Номинальная вместимость ковша |
0.5m3 |
Overall dimensions (LxWxH) |
4750x1730x2600mm |
| Bucket width |
1700mm |
Модель двигателя |
CHANGCHAI 490 |
| Track base |
1400mm |
Engine type |
In-line arrangement, water cooled,
four-cyclediesel engine |
| Колесная база |
1580mm |
Engine starting mode |
Электрический |
| Min. turning radius(outside of rear wheels) |
4000mm |
Rated power/Rated speed |
39KW/2200rpm |
| Min. Ground clearance |
230mm |
Brake mode |
Four-wheel hydraulic spread-shoed brake |
| Dump height fully raised |
2200 мм |
Гарантия |
12months after received the goods |
| Reach fully raised |
850mm |
Color |
According to the requirements of
customers |
| Lifting time |
4S |
Tyre type |
8.25-16 |
| Hydraulic cycle time |
9S |
Shipping port |
Qingdao port, China |
| Max. Tilt angle |
300 |
Packing details |
Nude package, 1Unit/20’s GP withdisassembled cabin, 3Units/40’s HQ |
| Max. Bucket breakout, lift cylinder |
26KN |
Delivery time |
20 days after confirm the order |
| Driving mode |
Four-whee l drive |
Supply ability |
100 units per month |
