THE TECHNICAL PARAMETERS OF ZL15F CE CERTIFICATE MINI WHEEL LOADER |
|||
|
Item |
Specifications |
Item |
Specifications |
| Rated loading weight | 1500kg | Operating weight | 3600kg |
| Rated bucket capacity | 0.7m3 | Overall dimensions(LxWxH) | 4870x1750x2650mm |
| Bucket width | 1700mm | Engine model | XINCHAI 498(EURO III) |
| Track base | 1400mm | Engine type | In-line arrangement, water cooled, four-cycle diesel engine |
| Wheel base | 1950mm | Engine starting mode | Electric |
| Min. turning radius(outside of rear wheels) | 4400mm | Rated power/Rated speed | 36.8KW/2650rpm |
| Min. Ground clearance | 270mm | Brake mode | Four-wheel hydraulic spread-shoed brake |
| Dump height fully raised | 2580mm | Warranty | 12 months after received the goods |
| Reach fully raised | 860mm | Color | According to the requirements |
| Lifting time | <5.0S | Tyre type | 12-16.5 wide tyre |
| Max. Tilt angle | 300 | Shipping port | Qingdao port, China |
| Max. Bucket breakout, lift cylinder | 42KN | Packing details | Nude package, 1Unit/20’s GP with disassembled cabin, 3Units/40’s HQ |
| Maximum Speed | 21km/h | Delivery time | 20 days after confirm the order |
| Driving mode | Four-wheel full hydraulic drive | Supply ability | 100 units per month |
| Transmission gear box form | 2 gear hydraulic variable speed changes | ||
