THE TECHNICAL PARAMETERS OF ZL08F CE CERTIFICATE MINI WHEEL LOADER |
|||
|
Item |
Specifications |
Item |
Specifications |
| Rated loading weight | 800kg | Operating weight | 2850kg |
| Rated bucket capacity | 0.4m3 | Overall dimensions(LxWxH) | 4100x1600x2450mm |
| Bucket width | 1400mm | Engine model | Changchai 390 |
| Track base | 1285mm | Engine type | In-line arrangement, water cooled, two-cycle diesel engine |
| Wheel base | 2170mm | Engine starting mode | Electric |
| Min. turning radius(outside of rear wheels) | 4600mm | Rated power/Rated speed | 25KW/2200rpm |
| Min. Ground clearance | 240mm | Brake mode | Four-wheel hydraulic spread-shoed brake |
| Dump height fully raised | 2300mm | Warranty | 12 months after received the goods |
| Reach fully raised | 750mm | Color | According to the requirements of customers |
| Lifting time | 4S | Tyre type | 8.25-16 |
| Hydraulic cycle time | 9S | Shipping port | Qingdao port, China |
| Max. Tilt angle | 300 | Packing details | Nude package, 1Unit/20’s GP, 4Units/40’s HQ |
| Max. Bucket breakout, lift cylinder | 28KN | Delivery time | 15 days after confirm the order |
| Driving mode | Four-wheel drive | Supply ability | 100 units per month |
